801.	High‐purity GaAs layers grown by low‐pressure metalorganic chemical vapor deposition M. Razeghi; F. Omnes; J. Nagle; M. Defour; O. Acher; P. Bove Appl. Phys. Lett. 55, 1677–1679 (1989)-- October 16, 1989 We report electrical and optical properties of very high purity GaAs epilayers grown by low‐pressure metalorganic chemical vapor deposition using AsH3 and triethylgallium as As and Ga sources. An electron mobility of 335 000 cm2/V s at 38 K has been measured for a 12‐μ‐thick layer. reprint
802.	Electron-spin resonance of the two-dimensional electron gas in Ga0.47In0.53As-InP heterostructures M. Dobers, J. P. Vieren,, Y. Guldner P. Bove, F. Omnes, and M. Razeghi Phys. Rev. B 40, 8075(R) – Published 15 October, 1989-- October 15, 1989 The microwave-induced change of the magnetoresistivity of Ga0.47In0.53As-InP heterostructures reveals resonant structure which is attributed to electron-spin resonance of the two-dimensional conduction electrons. With microwave frequencies up to 480 GHz and in magnetic fields up to 12 T, we studied the spin splitting of the two lowest Landau levels in different samples. The spin splitting of these Landau levels is a quadratic function of the magnetic field and its extrapolation to zero magnetic field leads to vanishing spin splitting. The g factors depend on the magnetic field B and the Landau level N as follows: g(B,N)=𝑔0-c(N+1/2)B, where 𝑔0 and c are sample-dependent parameters, which are of the order of 𝑔0≊4.1 and c≊0.08 T−1, in the studied heterostructures. reprint
803.	Electron capture processes in optically excited In0.53Ga 0.47As/InP quantum wells U. Cebulla*, G. Bacher, A. Forchel, D. Schmitz, H. Jürgensen, M. Razeghi Appl. Phys. Lett. 55, 933–935 (1989)-- September 4, 1989 We have performed picosecond time-resolved measurements on Ir:.O. 53 GaO. 47 As/lnP quantum wells with varying barrier thicknesses using 10 ps Nd:Y AG excitation. For this excitation, holes and electrons are created in the Ino . 53 GaOA7 As layers. Due to momentum conservation the Nd:YAG excitation accelerates the electrons above the InP barrier where they can diffuse but cannot recombine. By examining the rise time of the quantum well emission, we can show that for samples with thick barriers, the harrier geometry largely controls the dynamic properties of the carriers after Nd:YAG excitation. reprint
804.	Extremely high electron mobility in a GaAs‐GaxIn1−xP heterostructure grown by metalorganic chemical vapor deposition M. Razeghi; M. Defour; F. Omnes; M. Dobers; J. P. Vieren; Y. Guldner Appl. Phys. Lett. 55, 457–459 (1989)-- June 17, 1989 On studying the magnetoresistivity of GaAs-GalnP heterostructures grown by low-pressure metalorganic chemical vapor deposition in magnetic fields up to 12 T and at liquid-helium temperatures, we have observed extremely high electron mobilities. Using the persistent photoconductivity effect, by illumination with red light, we reached a mobility of 780 000 cm2 / (V s) at an electron density of 4.1 X lOll cm- 2 . This high electron mobility is confirmed by cyclotron resonance measurements< reprint
805.	Electron spin resonance in the two-dimensional electron gas of a GaAs-Gax In1-xP heterostructure M DoberstS, J P Vierent, M RazeghiS, M DefourS and F Ornnes Semicond. Sci. Technol. 4 (1989) 687-690-- June 12, 1989 The microwave-induced change of the magnetoresistivity of GaAs-GalnP heterostructures reveals resonant structure which is attributed to electron spin resonance of the two-dimensional conduction electrons. The spin splitting of the two lowest Landau levels has been investigated as a function of the magnetic field. From these studies we obtain the dependence of the g-factor on the magnetic field and the Landau level. These results are compared with those obtained in GaAs-AIGaAs heterostructures. reprint
806.	Recent advances in III–V compounds on silicon M. Razeghi M. Razeghi, Recent advances in III–V compounds on silicon, Progress in Crystal Growth and Characterization, Volume 19, Issues 1–2, 1989, Pages 21-37,-- January 1, 1989 The performance of photonic and electronic devices fabricated with III–V compounds on silicon substrate has advanced to the degree that this technology may be considered for device applications. In this paper, the recent advances on the growth, characterization, and applications of III–V compounds on Si substrates using low pressure metalorganic chemical vapor deposition growth technique are presented.
807.	Monolithic integration of a short‐length GaInAs photoconductor with a GaAs/GaAlAs optical waveguide on a GaAs semi‐insulating substrate F. Mallecot; J. F. Vinchant; M. Razeghi; D. Vandermoere; J. P. Vilcot; D. Decoster Appl. Phys. Lett. 53, 2522–2524 (1988)-- December 19, 1988 We report the first fabrication of a GaO. 47 Inn. 53 As planar photoconductive detector, associated with a GaAs/GaAIAs rib waveguide grown on a semi-insulating GaAs substrate, which needs a short-length absorbing layer to detect the optical signal. Because of the GaAIAs epilayer, a GalnAs length of about 100 tl1n only is needed to detect 90% of the opticai signal, accordingly to results predicted using a four-layer model with complex refractive indices in each layer. reprint
808.	First cw operation of a Ga0.25In0.75As0.5P0.5‐InP laser on a silicon substrate M. Razeghi; M. Defour; R. Blondeau; F. Omnes; P. Maurel; O. Acher; F. Brillouet; J. C. C‐Fan; J. Salerno Appl. Phys. Lett. 53, 2389–2390 (1988) -- December 12, 1988 We report the first successful room-temperature cw operations of a GaO. 25 1110.75 ASo. 5 po. s -InP buried ridge structure laser emitting at 1.3 f-tm grown by two-step low-pressure metalorganic chemical vapor deposition on a silicon substrate. An output power of 20 m W with an external quantum efficiency of 16% at room temperature has been obtained. A threshold current as low as 45 rnA under cw operation at room temperature has been measured. The first cw aging test at room temperature, at 2 mW during 5 h, shows a very low degradation (Ill 11,;;5%). reprint
809.	Pressure-induced depopulation of the first excited subband in GaInAs/InP heterojunctions D Gauthier, J C Portal and M Razeghi D Gauthier et al 1989 Semicond. Sci. Technol. 4 218-- December 8, 1988 Following our previous work on (GalnAs)/(lnP) heterojunctions under hydrostatic pressure we present recent experimental results where the evidence for the total depopulation of the first excited electric subband with pressure is demonstrated. The total electron concentration decreases at a rate of 2.7% kbar”, much higher than in previous experiments. The experimental situation can be fitted with the triangular-well approximation if we both assume the change with pressure of the conduction band discontinuity AE, and the deepening of a deep impurity level with activation energy of the order 160 meV at zero pressure. reprint
810.	Persistent photoconductivity in Ga0.49In0.51P/GaAs heterojunctions S. Ben Amor; L. Dmowski; J. C. Portal; N. J. Pulsford; R. J. Nicholas; J. Singleton; M. Razeghi J. Appl. Phys. 65, 2756–2760 (1989-- November 18, 1988 We have studied the persistent photoconductivity (PPC) effect in Ga0.49 Ino. sl P IGaAs heterostructures. Through time- and temperature-dependent Hall effect, we observe very small relaxation rates and the PPC remains observable at room temperature. Optical experiments show an optical energy threshold of 1.15 e V and an infrared quenching of the ppc. Thermal cycling of the samples strongly affects the PPC and the quenching temperature. The center responsible for the observed PPC, therefore, appears related to defects, Most of our observations are qualitatively understood in a large lattice relaxation DX-like center approach. However, the origin of the high quenching temperature remains to be explained. reprint
811.	First GaInAsP‐InP double‐heterostructure laser emitting at 1.27 μm on a silicon substrate Available M. Razeghi; M. Defour; F. Omnes; Ph. Maurel; J. Chazelas; F. Brillouet Appl. Phys. Lett. 53, 725–727 (1988)-- August 29, 1988 We report the first successful room-temperature GalnAsP-InP double-heterostructure laser emitting at 1.27 pm, grown by low-pressure metalorganic chemical vapor deposition on a Si substrate. A pulsed threshold current density of 10 kAlcm2 at room temperature with an external quantum efficiency of 10% per facet and an output power of20 mW (for an oxidedefined stripe geometry with 12 pm stripe width and 250 pm cavity length) has been measured. The first aging test in pulse operation shows an increase of threshold current of only 7% for a cumulative time of 80 s at room temperature. reprint
812.	First room‐temperature cw operation of a GaInAsP/InP light‐emitting diode on a silicon substrate M. Razeghi; R. Blondeau; M. Defour; F. Omnes; P. Maurel; F. Brillouet Appl. Phys. Lett. 53, 854–855 (1988)-- July 4, 1988 We report in this letter the first successful fabrication of an InP-GalnAsP light-emitting diode, emitting at 1.15 pm grown by low-pressure metalorganic chemical vapor deposition on a silicon substrate. The device has been operated under continuous wave operation at room temperature for 24 h (with an injection current of 200 rnA), and showed no degradation. reprint
813.	First GaInAsP‐InP double‐heterostructure laser emitting at 1.27 μm on a silicon substrate M. Razeghi; M. Defour; F. Omnes; Ph. Maurel; J. Chazelas; F. Brillouet Appl. Phys. Lett. 53, 725–727 (1988)-- June 21, 1988 We report the first successful room-temperature GalnAsP-InP double-heterostructure laser emitting at 1.27 pm, grown by low-pressure metalorganic chemical vapor deposition on a Si substrate. A pulsed threshold current density of 10 kAlcm2 at room temperature with an external quantum efficiency of 10% per facet and an output power of20 mW (for an oxidedefined stripe geometry with 12 pm stripe width and 250 pm cavity length) has been measured. The first aging test in pulse operation shows an increase of threshold current of only 7% for a cumulative time of 80 s at room temperature. reprint
814.	High‐quality GaAs/Ga0.49In0.51P superlattices grown on GaAs and silicon substrates by low‐pressure metalorganic chemical vapor deposition Available M. Razeghi; Ph. Maurel; F. Omnes; M. Defour; C. Boothroyd; W. M. Stobbs; M. Kelly J. Appl. Phys. 63, 4511–4514 (1988) -- May 1, 1988 We report the successful growth of Ga0.49 Iuo.5 ! P-GaAs superlattices on GaAs and Si substrates by low-pressure metalorganic chemical vapor deposition. The high quality of the structure grown on GaAs and silicon substrates has been evidenced by transmission electron microscopy photographs, that show very sharp interfaces between GaAs wells and Gao.49InO.51 P barriers, with perfect control of thicknesses and compositions. Classical Hall measurements performed on the sample further demonstrated the presence of a twodimensional electron ga.<; with a mobility at T = 4 K , fL (4 K) = 50000 cm2 1V Is, and a carrier concentration n _ (4 K) = 2,9 X 1011 em -2. GaAs/Gao.49 InO. 51 P superlattices have been used, as well as buffer layer in order to grow GaAs on silicon substrates. Mirrorlike single-crystal GaAs has thus been obtained. A GaInP IGaAs heterostructure with electron HaH mobility as high as 6000 cm2 /V Is at 300 K and 80000 cm2 /V Is at 4 K has been grown, which is the highest mobility that has yet been reported for these materials, reprint
815.	Monolithic integrated photoreceiver for 1.3–1.55‐μm wavelengths: Association of a Schottky photodiode and a field‐effect transistor on GaInP‐GaInAs heteroepitaxy A. Hosseini Therani; D. Decoster; J. P. Vilcot; M. Razeghi J. Appl. Phys. 64, 2215–2218 (1988) -- March 24, 1988 We present a monolithic integrated circuit associating a Schottky photodiode and a field-effect transistor which has been fabricated, for the first time, on G8.0.49 InO.51 P /GaO,47 Ino.53 As strained heteroepitaxiaI material. Static, dynamic, and noise properties of the Schottky photodiode, the field-effect transistor, and the integrated circuit have been investigated and are reported. As an example, dynamic responsivity up to 50 A/W can be achieved at 1.3-pm wavelength for the integrated photoreceiver. The performance of the device is discussed, taking into account the integrated circuit design and the main characteristics of the material. reprint
816.	MOCVD challenge for III-V semiconductor materials for photonic and electronic devices on alternative substrates M. Razeghi, M. Defour , F. Omnes, P. Maurel , E. Bigan , O. Acher, J. Nagle, F. Brillouet , J.C. Portal M. Razeghi, M. Defour, F. Omnes, P. Maurel, E. Bigan, O. Acher, J. Nagle, F. Brillouet, J.C. Portal, MOCVD challenge for III-V semiconductor materials for photonic and electronic devices on alternative substrates, Journal of Crystal Growth, Volume 93, Issues 1–4, 1988, Pages 776-781,-- January 1, 1988 High quality II[-V semiconductor heterojunctions, quantum wells and superlauices have been grown on lattice matched and alternative substrates such as silicon for photonic and electronic devices, using low pressure metalorganic chemical vapor deposition growth technique. reprint
817.	First observation of quantum Hall effect in a GaInAsP‐InP heterostructure grown by metalorganic vapor deposition M. Razeghi; P. Maurel; F. Omnes; M. Defour; O. Acher; D. Tsui; H. P. Wei; Y. Guldner; J. P. Vieren Appl. Phys. Lett. 51, 1821–1823 (1987) -- November 30, 1987 We report the first observation of quantum Han effect in a Gao.25 Ino.75 Aso.s P 0.5 heterostructure grown by metal organic chemical vapor deposition growth technique. reprint
818.	Pressure dependence study of the effective mass in Ga0.47In0.53As/InP heterojunctions D. Gauthier , L. Dmowski, J.C. Portal D. Leadley, M.A. Hopkins , M.A. Brummell , R.J. Nicholas, M. Razeghi, P. Maurel D. Gauthier, L. Dmowski, J.C. Portal, D. Leadley, M.A. Hopkins, M.A. Brummell, R.J. Nicholas, M. Razeghi, P. Maurel, Pressure dependence study of the effective mass in Ga0.47In0.53As/InP heterojunctions, Superlattices and Microstructures, Volume 4, Issue 2, 1988, Pages 201-206-- August 17, 1987 A study of the effective mass in GaInAs/InP heterojunctions under hydrostatic pressure up to 15 kbars is presented. Earlier results have shown the importance of hydrostatic pressure effects on the band parameters of the heterojunction to explain the experimental decrease of the carrier concentration with pressure at the interface (1). Here magnetophonon resonance experiments are performed to work out the increase of mass with pressure in our samples. The effective mass at atmospheric pressure is deduced from high temperature cyclotron resonance experiments and then used to calculate the frequency of the phonon interacting with the 2D electron gas (wo). The value of wo is found to be dependent on the carrier concentration of the measured samples. The lowest value is found for the highest carrier concentration sample. A band edge effective mass increase of 1 ± .1% kbar is found in the highest carrier concentration sample. This is two times smaller than the rate found experimentally in GaInAs bulk material and slightly smaller than in an AlInAs/GaInAs heterojunction. The experimental increase could be fitted with multiband k.p theory assuming no pressure dependence for the conduction band-valence band matrix element Ep. However at lower concentration a variation of the matrix element Ep with pressure has to be considered. reprint
819.	Disorder of a Gax In1-xAsy P1-y-InP quantum well by Zn diffusion M. Razeghi, O. Acher, and F. Launay Semicond. Sci. Technol. 2 (1 987) 793-796.-- July 30, 1987 Data are presented showing for the first time that Zn diffusion into a Ga,In,-,As,P,-, - InP quantum well and superlattice (of 100 A thickness) completely disorders the quantum well and superlattice layers. The photoluminescence wavelength of the quantum well and the superlattice increased after Zn diffusion, which can be attributed to the In-Ga interdiffusion at the heterointerfaces, as a result of the interchange mechanism between the interstitials and substitutional zinc atoms reprint
820.	cw phase‐locked array Ga0.25In0.75As0.5P0.5‐InP high power semiconductor laser grown by low‐pressure metalorganic chemical vapor deposition M. Razeghi; R. Blondeau; M. Krakowski; B. de Cremoux; J. P. Duchemin; F. Lozes; M. Martinot; M. A. Bensoussan Appl. Phys. Lett. 50, 230–232 (1987)-- February 2, 1987 Continuous and pulsed phase-locked operation of a high power GalnAsP-InP semiconductor laser emi.tting at 1.3 f1m has been achieved. The laser consists ofa seven-striped array of ridgeisland lasers fabricated by a two-step low-pressure metalorgallic chemical vapor deposition growth technique. Linear output powers greater than 300 mW (pulsed) and 120 mW (cw) have been obtained with no facet coatings. The far-field full widths at half power, both paranel and perpendicular to the junction plane, were Y and 4Y, respectively, at 10 mW (at 20°C) which is evidence for strong stripe-to-stripe coupling. reprint
821.	Room‐temperature excitons in Ga0.47In0.53As‐InP superlattices grown by low‐pressure metalorganic chemical vapor deposition M. Razeghi; J. Nagle; P. Maurel; F. Omnes; J. P. Pocholle Appl. Phys. Lett. 49, 1110–1111 (1986)-- October 27, 1986 Very high quality Gao.47 InO. 53 As-InP heterojunctions, quantum wells, and superlattices have been grown by low-pressure metalorganic chemical vapor deposition. Excitation spectroscopy shows evidence of strong and wen-resolved exciton peaks in the luminescence and excitation spectra of GalnAs-lnP quantum wells. Optical absorption spectra show room-temperature excitons in GalnAs· InP superlattices. reprint
822.	Planar monolithic integrated photoreceiver for 1.3–1.55 μm wavelength applications using GaInAs‐GaAs heteroepitaxies M. Razeghi; J. Ramdani; H. Verriele; D. Decoster; M. Constant; J. Vanbremeersch Appl. Phys. Lett. 49, 215–217 (1986)-- July 28, 1986 We report the first fabrication of a monolithic integrated circuit consisting of a G1lo47 IIlo53 As planar photoconductive detector (suitable for 1.3-1.55 f.lm wavelength optical communication systems) associated with a GaAs field-effect transistor. The gain, response times, and noise properties of the photoconductive detector and the integrated photo receiver have been investigated, taking into account particular aspects of the material and integrated circuit structure. reprint
823.	Concentration gradient at an InP/GaAs interface determined by Auger analysis on a chemical bevel J. Cazaux; P. Etienne; M. Razeghi J. Cazaux, P. Etienne, M. Razeghi; Concentration gradient at an InP/GaAs interface determined by Auger analysis on a chemical bevel. J. Appl. Phys. 15 May 1986; 59 (10): 3598–3601-- June 15, 1986 Experimental results of Auger profiles obtained on a chemical bevel of an InP/GaAs structure are reported. A theoretical procedure is established to convert the intensity profile into concentration profiles. It is applied to evaluate the concentration distribution of each species–Ga, In, As, P–independently of each others with a precision of ±5%. It is verified that the composition of the interface is GaxIn1−xAsyP1−y (0≤x, y≤1). Owing to differences between the atomic diffusions of III‐ and V‐type elements, the transition region can be subdivided into three regions having the following compositions: (i) GaAsyP1−y with 0.87≤y≤1; (ii) GaxIn1−xAsyP1−y with 0≤y≤0.87 and 0.24≤x<1; (iii) PGaxIn1−x with x<0.24. The width of each region is also indicated. reprint
824.	First observation of the two‐dimensional properties of the electron gas in Ga0.49In0.51P/GaAs heterojunctions grown by low pressure metalorganic chemical vapor deposition M. Razeghi; P. Maurel; F. Omnés; S. Ben Armor; L. Dmowski; J. C. Portal M. Razeghi, P. Maurel, F. Omnés, S. Ben Armor, L. Dmowski, J. C. Portal; First observation of the two‐dimensional properties of the electron gas in Ga0.49In0.51P/GaAs heterojunctions grown by low pressure metalorganic chemical vapor deposition. Appl. Phys. Lett. 12 May 1986; 48 (19): 1267–1269-- June 12, 1986 We report the first observation of a two‐dimensional electron gas from Shubnikov–de Haas and quantum hall effect experiments in GaInP/GaAs heterostructures grown by low pressure metalorganic chemical vapor deposition. Angular‐dependent Shubnikov–de Haas measurements confirm two dimensionality of the system. Low‐temperature persistent photoconductivity was observed. Critical density at which the second electric subband starts to be populated was determined to be 7.3×1011 cm−2. reprint
825.	An experimental test of two-parameter scaling of integral quantum Hall effect H.P. Wei a b , A.M. Chang a b ∗, D.C. Tsui a b, A.M.M. Pruisken c d, M. Razeghi Wei, H. P., Chang, A. M., Tsui, D. C., Pruisken, A. M. M., & Razeghi, M. (1986). An experimental test of two-parameter scaling of integral quantum Hall effect. Surface Science, 170(1–2), 238–242. -- April 3, 1986 Detailed measurements are made of the temperature and magnetic field dependences of the magneto-transport coefficients, oK, and o,~, in an ln0.53Ga0.4vAs-lnP heterostructure to test the (two-parameter) renormalization group theory of the integral quantum Hall effect.
